MIAXIS SM-92 Series, FAP20 Optical Fingerprint Scanner are all FBI-PIV&FAP20 certified optical fingerprint scanners, each built on corresponding OEM modules as specified in their technical documents:
All models provide mainstream Windows/Android/Linux SDK for easy integration into biometric authentication and individual identity verification scenarios, making them ideal for ID verification and IT security.
OVERVIEW
MIAXIS SM-92 Series, FAP20 Optical Fingerprint Scanners are all FBI-PIV&FAP20 certified optical fingerprint scanners, each built on corresponding OEM modules as specified in their technical documents:
All models provide mainstream Windows/Android/Linux SDK for easy integration into biometric authentication and individual identity verification scenarios, making them ideal for ID verification and IT security.
FEATURES
Certificates & Compliance
FBI PIV and FBI Mobile ID FAP20 certificates
Biometric standard: ISO 19794-4, ANSI 381, WSQ, JPEG, RAW, BMP, MINEX III compliant
Live Fingerprint Detection
Machine-learning-based live finger detection technology to differentiate fake fingers
Auto-reject fake materials including silicon, paper, rubber and more
Easy Integration
SDKs available for Android, MS Windows and Linux compatible
UART&USB multiple interfaces
Advanced Algorithm
Template options: MIAXIS, ISO 19794-2 & ANSI 378
Miaxis proprietary Justouch® fingerprint extractor & matcher passed NIST MINEX III compliance
Value-added customised APIs for software integration
Dustproof and Waterproof
IP65 dustproof and waterproof
MIAXIS SM-92M is an FBI-PIV&FAP20 certified Optical Fingerprint OEM Module, with a lightweight and compact 15mm slim design. SM-92M can be easily assembled into handheld or tablet mobile authentication devices for indoor and outdoor uses. Perfect for large-scale identity verification allows a wide range of applications.
Parameter Comparison
| Specification | SM-92 OEM Module SM-92M | SM-92-C OEM Module SM-92M-C | SM-92-S OEM Module SM-92M-S | SM-92-P OEM Module SM-92M-P |
| Product Size (L x W x H mm) | 78 x 46 x 24 | 78.0 x 46.0 x 24.0 | 78 x 46 x 24 | 78.0 x 46.0 x 24.0 |
| Sensor Area (L x W mm) | 16 x 21 | 16.0 x 21.0 | 16 x 21 | 16.0 x 21.0 |
| Weight | 81g | 81g | 81g | 81g |
| Sensor Type | Optical Sensor | Optical Sensor | Optical Sensor | Optical Sensor |
| Image Spec | FBI PIV&FAP20 | FBI PIV&FAP20 | FBI PIV&FAP20 | FBI PIV&FAP20 |
| Image Resolution | 500 dpi | 500 dpi | 500 dpi | 500 dpi |
| Image Size (W x H pixel) | 300 x 400 | 300 x 400 | 300 x 400 | 300 x 400 |
| Grey Scale | 8bit, 256 levels | 8bit, 256 levels | 8bit, 256 levels | 8bit, 256 levels |
| Image Format | WSQ, JPEG2000, RAW, BMP, ISO 19794-4, ANSI 381 | RAW | WSQ, JPEG2000, RAW, BMP, ISO 19794-4, ANSI 381 | RAW |
| Quality Score | NFIQ 1.0 | NFIQ 1.0 | NFIQ 1.0 | NFIQ 1.0 |
| Live Finger Detection | Yes | Yes | Yes | Yes |
| Latent Detection | Yes | Yes | Yes | Yes |
| Enrollment Time | ≤0.5s (collect one image and upload by USB) | ≤0.5s (collect one image and upload by USB) | ≤0.5s (collect one image and upload by USB) | ≤0.5s (collect one image and upload by USB) |
| Max. Encryption Capture Time (MOSIP) | / | / | ≤3 seconds (Including capture, wsq, encryption and signing & transfer via USB) | ≤3 seconds (Including capture, wsq, encryption and signing & transfer via USB) |
| FTM (MOSIP) | / | / | SBI 2.0-FTM | SBI 2.0-FTM supported security |
| Capturing Indication | Start of capturing: Lamp On; End of capturing: Lamp Off | Start of capturing: Lamp On; End of capturing: Lamp Off | Start of capturing: Lamp On; End of capturing: Lamp Off | Start of capturing: Lamp On; End of capturing: Lamp Off |
| Supply Voltage | DC5V±5% (USB powered) | DC5V±5% (USB powered) | DC5V±5% (USB powered) | DC5V±5% (USB powered) |
| Supply Current (USB powered) | ≤200mA | ≤200mA | ≤200mA | ≤200mA |
| Communication Interface | USB 2.0/3.0 | USB 2.0 | USB 2.0/3.0 | USB 2.0 |
| ESD Immunity (Sensor Surface) | ±8kV contact discharge, ±15kV air discharge | ±8kV contact discharge, ±15kV air discharge | ±8kV contact discharge, ±15kV air discharge | ±8kV contact discharge, ±15kV air discharge |
| Operating Temperature | -10℃ to +50℃ | -10℃ to +50℃ | -10℃ to +50℃ | -10℃ to +50℃ |
| Storage Temperature | -20℃ to +60℃ | -20℃ to +60℃ | -20℃ to +60℃ | -20℃ to +60℃ |
| Operating Humidity | 20%RH～90%RH | 20%RH～90%RH | 20%RH～90%RH | 20%RH～90%RH |
| Ingress Protection | IP65 (Sensor Surface) | IP65 (Sensor Surface) | IP65 (Sensor Surface) | IP65 (Sensor Surface) |
| Operating System Environment | Linux Kernel 4.15 or higher; Windows 7 or higher; Android 4.1 or higher | Linux Kernel 4.15 or higher; Windows 7 or higher; Android 4.1 or higher | Linux Kernel 4.15 or higher; Windows 7 or higher; Android 4.1 or higher | Linux Kernel 4.15 or higher; Windows 7 or higher; Android 4.1 or higher |
